Luminous NXI 320 20KW 3Phase Solar Grid Tie Inverter comes with 98.6% Max. efficiency Wide voltage range and low start-up voltage Friendly and adaptable connection to the grid Super high frequency switching technology Precise MPPT algorithm Compact and lightweight WiFi/GPRS Real time monitoring Safe for your home with comprehensive protection features such as short-circuit, reverse polarity, anti-islanding, residual current detection and user-friendly Informative LCD Display.

*FREE Delivery

Luminous NXI 320 20KW 3Phase Solar Grid Tie Inverter

Name: Luminous NXI 320 20KW 3Phase Solar Grid Tie Inverter
Brand: LUMINOUS
SKU: UPS_NXI 320GRIDTIEINVERTER_001
Price: 117000 INR
Availability: InStock

₹3,48,000.00

₹1,17,000.00

Quantity

Luminous NXI Grid Tie Inverter are power Inverter that can feed power from solar panels directly to grid.

They are designed to quickly disconnect from the grid if the utility grid goes down (anti-islanding).

More than 97% efficiency The transformer-less design makes Luminous GTI highly efficient to deliver maximum Solar Power.

Dual/Quad MPPTs provides you the flexibility of connecting multiple arrays, which helps minimize the impact of shading, increases efficiency, resulting in more solar generation.

IP66 Protection Luminous GTI is IP 66 certified product hence it is suitable for outdoor Installation also.

It can work in extreme weather conditions such as dust, heavy rains, excessive heat or extreme cold.

Anti-Islanding protection: This does not send electricity to grid if Grid has failed, thereby ensures complete safety of line workers.

Wi-Fi and Remote Monitoring Users can connect with Luminous GTI using Wi-Fi and access information and diagnostics via smartphone.

MNRE & IEC compliance GTI complies with all the National & International standards for safety and efficiency and reliability, such as IEC - 61683, IEC - 60068, IEC - 61000, IEC - 61727, IEC - 62116
Package Contents: 1N Inverter, 1N Manual

Dimensions (in cms): 31.0*21.9*60.8CM

VA Rating: 20KW

No. of Batteries Supported: NA

Maximum Panel Capacity (W): 24000Wp

Nominal Battery bank voltage: NA

Application Area: Commercial Applications, Homes and Small Shops

Product Category: On-Grid

Input Voltage Range: 160V-1000V

Features: Transformer less GTI with efficiency of more than 97% Inbuilt MPPT charge controllers to extract upto 30% more power from panels Wide operating voltage range to extend usable operation of panels IP65 enclosure: Dust and waterproof, can be installed outside Communication : for remote monitoring

Warranty: 60 Months Manufacturer's Warranty.
